SPEC SHEETS

THE WHITE

  • COMPONENTS

    • Brake System: Hydraulic brakes
    • Brake Rotors: 160mm
    • Crank Set: 52T with 170mm arms
    • Derailleur: Shimano Altus RD 7 Speed
    • Fork: Custom spring suspension
    • Frame: 6061 Aircraft Aluminum
    • Freewheel: 14-28T Shimano 7 Speed
    • Grips: Ergonomic rubber comfort grips
    • Handlebars: Aluminum riser bars
    • Kickstand: Adjustable, side mounted
    • Seat post: 30.4mm x 350mm
    • Shifter: Shimano 7 speed thumb shifter
    • Stem: 95 – 97.5 ±0-40°
    • Tires: 26” x 2”

  • ELECTRONICS

    • Battery: Integrated 36V 12.8Ah 460Wh Panasonic lithium ion battery
    • Battery Certification: UL 2849
    • Class: 2
    • Display: Water resistant, LED with speed, power, battery, and distance indicators
    • USB: 1 port
    • Motor: Bafang 500W, 45nm of torque
    • Pedal assist: 0-5 levels (cadence sensing)
    • Throttle: Thumb operated
    • Range: 25-60mi

  • GEOMETRY

    • Recommended rider height: 5’2” – 6’2”
    • Bike weight: 43lbs
    • Payload capacity: 350lbs
    • Towing capacity: 125lbs
    • Handlebar height: 42” (1066.8mm)
    • Reach: 14.75” (374.65mm)
    • Seat height: 33” – 39.5” (838.2 – 1003mm)
    • Stand over height: 30” (762mm)
    • Step over height: 27.25” (692.15mm)
    • Wheelbase: 42” (1069.19mm)
    • Total length: 68” (1727.2mm)
    • Seat tube length: 18.5” (470mm)
    • Top tube length: 22.5” (573.42mm)

  • ────────────────────────────────────────────────────────────────────────────────────────────────────────

THE BLACK

  • COMPONENTS

    • Brake System: Hydraulic brakes
    • Brake Rotors: 160mm
    • Crank Set: 52T with 170mm arms
    • Derailleur: Shimano Altus RD 7 Speed
    • Fork: Custom spring suspension
    • Frame: 6061 Aircraft Aluminum
    • Freewheel: 14-28T Shimano 7 Speed
    • Grips: Ergonomic rubber comfort grips
    • Handlebars: Aluminum flat bars
    • Kickstand: Adjustable, side mounted
    • Seat post: 30.4mm x 350mm
    • Shifter: Shimano 7 speed thumb shifter
    • Stem: 70mm ±35°
    • Tires: 26” x 2”

  • ELECTRONICS

    • Battery: Integrated 36V 12.8Ah 460Wh Panasonic lithium ion battery
    • Battery Certification: UL 2849
    • Class: 2
    • Display: Water resistant, LED with speed, power, battery, and distance indicators
    • USB: 1 port
    • Motor: Bafang 500W, 45nm of torque
    • Pedal assist: 0-5 levels (cadence sensing)
    • Throttle: Thumb operated
    • Range: 25-60mi

  • GEOMETRY

    • Recommended rider height: 5’7” – 6’3”
    • Bike weight: 43lbs
    • Payload capacity: 350lbs
    • Towing capacity: 125lbs
    • Handlebar height: 40.5” (1028.7mm)
    • Reach: 15.5” (393.7mm)
    • Seat height: 35” – 41.5” (889 – 1054.1mm)
    • Stand over height: 33.25” (844.55mm)
    • Step over height: 31.5” (800.1mm)
    • Wheelbase: 42” (1069.19mm)
    • Total length: 68” (1727.2mm)
    • Seat tube length: 21.25” (540mm)
    • Top tube length: 22.25” (563.93mm)

  • ────────────────────────────────────────────────────────────────────────────────────────────────────────

THE CARGO

  • COMPONENTS

    • Brake System: Hydraulic brakes
    • Brake Rotors: 160mm
    • Crank Set: 52T with 170mm arms
    • Derailleur: Shimano Altus RD 7 Speed
    • Fork: Custom spring suspension
    • Frame: 6061 Aircraft Aluminum
    • Freewheel: 14-28T Shimano 7 Speed
    • Grips: No slip grips
    • Handlebars: Aluminum mustache bars
    • Kickstand: Bottom mounted
    • Seat post: 30.4mm x 350mm
    • Shifter: Shimano 7 speed thumb shifter
    • Stem: 87.5mm ±5°
    • Tires: 26” x 2” front, 20” x 2” rear

  • ELECTRONICS

    • Battery: Integrated 48V 10.5Ah 504Wh Panasonic lithium ion battery
    • Battery Certification: UL 2849
    • Class: 2
    • Display: Water resistant, LED with speed, power, battery, and distance indicators
    • USB: 1 port
    • Motor: Bafang 750W, 55nm of torque
    • Pedal assist: 0-5 levels (cadence sensing)
    • Throttle: Thumb operated
    • Range: 25-60mi

  • GEOMETRY

    • Recommended rider height: 5’2” – 6’2”
    • Bike weight: 53lbs
    • Payload capacity: 400lbs
    • Towing capacity: 200lbs
    • Handlebar height: 43.75” (1111.25mm)
    • Reach: 16.5” (419.1mm)
    • Seat height: 34” – 41.25” (863.6 – 1048mm)
    • Stand over height: 31.5” (800.1mm)
    • Step over height: 29” (736.6mm)
    • Wheelbase: 54.5” (1384.3mm)
    • Total length: 82.5” (2095.5mm)
    • Seat tube length: 14” (355.6mm)
    • Top tube length: 21” (533.4mm)
